SYSTEM 2150
Sliding patio doors
Customizable and versatile
up to
LC-PG45
NAFS (PG)
up to
DP50
Designed for Impact
down to
0.20
U-value*
Designed to maximize glass-to-wall ratio while offering superior durability, sound abatement and energy efficiency.
The
System 2150 sliding patio door is customizable and versatile, with
configurations for new construction and replacement in residential and
light commercial applications. The system is offered in white, beige,
clay and can be laminated with solid color or wood-grain foils.
Missing Gallery
Features
- Up to 1 1/4 in (32 mm) glazing channel accommodates triple glazing, increasing both energy efficiency and acoustical properties.
- 4 9/16 in (116 mm) frame depth provides flexibility for new construction and replacement projects.
- Engineered aluminum reinforcements provide excellent structural ratings
- High-definition finish for weather and stain resistance and ease of maintenance.
Performance
| Test Results | Description |
|---|---|
| NAFS (PG) | up to LC-PG55 |
| Designed for Impact | up to DP50 |
| U-value* | down to 0.20* |
*based on simulation
Performance in detail
Provides structural durability and reduced air and water infiltration
Provides flexibility for new construction and hassle-free replacement installation
Achieves superior resistance to water leakage
Provide excellent structural ratings
Accommodates triple glazing, increasing both energy efficiency and acoustical properties
Allow flexibility for X-O, O-X, O-X-O, O-XX-O operation
Offer flexibility for installation of jamb extensions, drywall returns and other accessories
Provides structural durability and reduced air and water infiltration
Provides flexibility for new construction and hassle-free replacement installation
Achieves superior resistance to water leakage
Provide excellent structural ratings
Accommodates triple glazing, increasing both energy efficiency and acoustical properties
Allow flexibility for X-O, O-X, O-X-O, O-XX-O operation
Offer flexibility for installation of jamb extensions, drywall returns and other accessories
